Signature 4-Bedroom Maisonette — Flat Roof
A modern double-storey family home for a 100 × 100 ft plot. The ground floor keeps family life open — living and dining flowing to the kitchen, a guest WC off the hall — with an attached DSQ (with its own bathroom) and a covered carport. Upstairs is the private floor: four bedrooms, three of them ensuite, plus a family bathroom off the landing. Clean parapet lines give it the contemporary flat-roof silhouette, rendered here in the white-modern palette.
- Bedrooms
- 4 (three ensuite + family bathroom)
- Ground floor
- Living/Dining · Kitchen · Guest WC · Hall · Stair · DSQ + DSQ bath · Carport
- Upper floor
- 4 bedrooms · 3 ensuites · family bathroom · landing
- Floor area
- 229.1 m² over two storeys
- Roof
- Flat, concealed behind parapets
- Fits plot
- from 100 × 100 ft (30.5 × 30.5 m)
Elemental BOQ, current rates version, ±10% band — not a quotation.
Front view — photoreal render of this exact plan.
Two-storey 3D cutaway: every room, exactly as drawn.
Presentation floor plans (the Floor-Plan Pack) — obscured here, to scale on purchase.
Interiors staged from the actual furniture layout.
Rear, both sides, aerial and roof — the rest of the nine views.
Inside the Technical Pack — obscured here, to scale on purchase.
Click any drawing to open it full-size. Use ← → to move through the set.
What each package gets you on this plan
Questions about this plan
Can this 4-bedroom maisonette plan change to fit my plot?
Yes — this is a generated plan, not a fixed stock drawing. Brief your actual plot dimensions, gate side and county in chat and the plan regenerates around them, re-checked against Kenyan residential code rules. The first pass and revisions are free to preview.
How much does it cost to build this 4-bedroom maisonette in Kenya?
KES 7.23M – 9.20M for the 229.1 m² set shown here — an elemental BOQ estimate at the current rates version with a ±10% band, not a quotation. The Technical Pack includes the priced Bill of Quantities behind that figure.
What do I get when I buy this plan?
Four packages, each including everything before it: the Floor-Plan Pack at KES 3,500 (presentation floor plan, clean), Plan + Views at KES 6,500 (full PDF set with all nine photoreal views), the Technical Pack at KES 9,500 (electrical and drainage schematics plus the priced BOQ), and the Stamped Set at KES 29,500 (BORAQS-registered architect's stamp, printed sets and DXF). All prices are VAT-inclusive.
Can I submit this plan for county approval?
With the Stamped Set, yes: a BORAQS-registered architect reviews the drawings and signs as architect of record before stamping. Until that review, every sheet is marked schematic pre-design — counties require the stamp to accept a submission.
Make this plan mine
Re-brief it to your plot, your bedroom count, your budget — two revisions free.
